Renesas瑞薩MCU微控制器RL78/G22
發布時間：2024-05-14 09:31:07 瀏覽：288
Renesas MCU微控制器RL78/G22具有以下特點：
1. 低功耗：在CPU工作時的電流消耗為37.5μA/MHz，在STOP模式下為200nA。
2. 豐富的電容觸摸通道。
3. 完備的16-48引腳封裝和32KB-64KB閃存，展開了新一代RL78通用微控制器的產品線。
4. 最大工作頻率為32MHz，廣泛的工作電壓范圍為1.6V-5.5V。
5. 增強的模擬和安全功能以及SNOOZE模式可編程控制器可大幅降低間歇工作的功耗。
6. 提供豐富的開發環境，包括評估板(Fast Prototyping Board)和智能配置器(Smart Configurator)。
7. 兼容現有的RL78系列，適用于家電、消費類電子產品到工業設備的廣泛用途。
具體技術參數包括：
- CPU型號：RL78核心，最高32MHz
- 工作電壓范圍：1.6V至5.5V
- 封裝類型：16引腳至48引腳
- 閃存容量：程序閃存：32-64KB，SRAM 4KB，數據閃存2KB
- 工作溫度范圍：可達105°C
- 增強型電容式感應單元(CTSU2L)
- 定時器：8路16位定時器、1路看門狗定時器、1路32位間隔定時器
- PWM輸出：7路PWM輸出
- 模擬功能：10路10位A/D轉換器
- 片上振蕩器頻率(MHz)：高速：最高32MHz，中速：最高4MHz，低速：32.768kHz
- 貪睡模式排序器
- 事件鏈路控制器
- 其他功能：RTC、上電復位、低電壓檢測
- 封裝類型：SSOP、LQFP、HWQFN、WFLGA
產品型號：
| Product ID | 程序存儲器 （KB） | 內存 （KB） | 溫度范圍 | 數據閃存 （KB） | I/O 端口 | 模數轉換器 | 產品尺寸 （mm） |
| R7F102G4C3CNP#AA0 | 32 | 4 | -40 to 105°C | 2 | 12 | 10-bit/8-bit x 3-ch | 3 x 3 x 0.8 |
| R7F102G4C3CNP#BA0 | 32 | 4 | -40 to 105°C | 2 | 12 | 10-bit/8-bit x 3-ch | 3 x 3 x 0.8 |
| R7F102G4C3CNP#HA0 | 32 | 4 | -40 to 105°C | 2 | 12 | 10-bit/8-bit x 3-ch | 3 x 3 x 0.8 |
| R7F102G4C2DNP#AA0 | 32 | 4 | -40 to 85°C | 2 | 12 | 10-bit/8-bit x 3-ch | 3 x 3 x 0.8 |
| R7F102G4C2DNP#BA0 | 32 | 4 | -40 to 85°C | 2 | 12 | 10-bit/8-bit x 3-ch | 3 x 3 x 0.8 |
| R7F102G4C2DNP#HA0 | 32 | 4 | -40 to 85°C | 2 | 12 | 10-bit/8-bit x 3-ch | 3 x 3 x 0.8 |
| R7F102G4E3CNP#AA0 | 64 | 4 | -40 to 105°C | 2 | 12 | 10-bit/8-bit x 3-ch | 3 x 3 x 0.8 |
| R7F102G4E3CNP#BA0 | 64 | 4 | -40 to 105°C | 2 | 12 | 10-bit/8-bit x 3-ch | 3 x 3 x 0.8 |
| R7F102G4E3CNP#HA0 | 64 | 4 | -40 to 105°C | 2 | 12 | 10-bit/8-bit x 3-ch | 3 x 3 x 0.8 |
| R7F102G4E2DNP#AA0 | 64 | 4 | -40 to 85°C | 2 | 12 | 10-bit/8-bit x 3-ch | 3 x 3 x 0.8 |
| R7F102G4E2DNP#BA0 | 64 | 4 | -40 to 85°C | 2 | 12 | 10-bit/8-bit x 3-ch | 3 x 3 x 0.8 |
| R7F102G4E2DNP#HA0 | 64 | 4 | -40 to 85°C | 2 | 12 | 10-bit/8-bit x 3-ch | 3 x 3 x 0.8 |
| R7F102G6C3CSP#CA0 | 32 | 4 | -40 to 105°C | 2 | 16 | 10-bit/8-bit x 6-ch | 4 x 6 x 1.45 |
| R7F102G6C3CSP#HA0 | 32 | 4 | -40 to 105°C | 2 | 16 | 10-bit/8-bit x 6-ch | 4 x 6 x 1.45 |
| R7F102G6C2DSP#CA0 | 32 | 4 | -40 to 85°C | 2 | 16 | 10-bit/8-bit x 6-ch | 4 x 6 x 1.45 |
| R7F102G6C2DSP#HA0 | 32 | 4 | -40 to 85°C | 2 | 16 | 10-bit/8-bit x 6-ch | 4 x 6 x 1.45 |
| R7F102G6E3CSP#CA0 | 64 | 4 | -40 to 105°C | 2 | 16 | 10-bit/8-bit x 6-ch | 4 x 6 x 1.45 |
| R7F102G6E3CSP#HA0 | 64 | 4 | -40 to 105°C | 2 | 16 | 10-bit/8-bit x 6-ch | 4 x 6 x 1.45 |
| R7F102G6E2DSP#CA0 | 64 | 4 | -40 to 85°C | 2 | 16 | 10-bit/8-bit x 6-ch | 4 x 6 x 1.45 |
| R7F102G6E2DSP#HA0 | 64 | 4 | -40 to 85°C | 2 | 16 | 10-bit/8-bit x 6-ch | 4 x 6 x 1.45 |
| R7F102G7C3CNP#AA0 | 32 | 4 | -40 to 105°C | 2 | 20 | 10-bit/8-bit x 6-ch | 4 x 4 x 0.8 |
| R7F102G7C3CNP#BA0 | 32 | 4 | -40 to 105°C | 2 | 20 | 10-bit/8-bit x 6-ch | 4 x 4 x 0.8 |
| R7F102G7C3CNP#HA0 | 32 | 4 | -40 to 105°C | 2 | 20 | 10-bit/8-bit x 6-ch | 4 x 4 x 0.8 |
| R7F102G7C2DNP#AA0 | 32 | 4 | -40 to 85°C | 2 | 20 | 10-bit/8-bit x 6-ch | 4 x 4 x 0.8 |
| R7F102G7C2DNP#BA0 | 32 | 4 | -40 to 85°C | 2 | 20 | 10-bit/8-bit x 6-ch | 4 x 4 x 0.8 |
| R7F102G7C2DNP#HA0 | 32 | 4 | -40 to 85°C | 2 | 20 | 10-bit/8-bit x 6-ch | 4 x 4 x 0.8 |
| R7F102G7E3CNP#AA0 | 64 | 4 | -40 to 105°C | 2 | 20 | 10-bit/8-bit x 6-ch | 4 x 4 x 0.8 |
| R7F102G7E3CNP#BA0 | 64 | 4 | -40 to 105°C | 2 | 20 | 10-bit/8-bit x 6-ch | 4 x 4 x 0.8 |
| R7F102G7E3CNP#HA0 | 64 | 4 | -40 to 105°C | 2 | 20 | 10-bit/8-bit x 6-ch | 4 x 4 x 0.8 |
| R7F102G7E2DNP#AA0 | 64 | 4 | -40 to 85°C | 2 | 20 | 10-bit/8-bit x 6-ch | 4 x 4 x 0.8 |
| R7F102G7E2DNP#BA0 | 64 | 4 | -40 to 85°C | 2 | 20 | 10-bit/8-bit x 6-ch | 4 x 4 x 0.8 |
| R7F102G7E2DNP#HA0 | 64 | 4 | -40 to 85°C | 2 | 20 | 10-bit/8-bit x 6-ch | 4 x 4 x 0.8 |
| R7F102G8C3CLA#AC0 | 32 | 4 | -40 to 105°C | 2 | 21 | 10-bit/8-bit x 6-ch | 3 x 3 x 0.76 |
| R7F102G8C3CLA#BC0 | 32 | 4 | -40 to 105°C | 2 | 21 | 10-bit/8-bit x 6-ch | 3 x 3 x 0.76 |
| R7F102G8C3CLA#HC0 | 32 | 4 | -40 to 105°C | 2 | 21 | 10-bit/8-bit x 6-ch | 3 x 3 x 0.76 |
| R7F102G8C2DLA#AC0 | 32 | 4 | -40 to 85°C | 2 | 21 | 10-bit/8-bit x 6-ch | 3 x 3 x 0.76 |
| R7F102G8C2DLA#BC0 | 32 | 4 | -40 to 85°C | 2 | 21 | 10-bit/8-bit x 6-ch | 3 x 3 x 0.76 |
| R7F102G8C2DLA#HC0 | 32 | 4 | -40 to 85°C | 2 | 21 | 10-bit/8-bit x 6-ch | 3 x 3 x 0.76 |
| R7F102G8E3CLA#AC0 | 64 | 4 | -40 to 105°C | 2 | 21 | 10-bit/8-bit x 6-ch | 3 x 3 x 0.76 |
| R7F102G8E3CLA#BC0 | 64 | 4 | -40 to 105°C | 2 | 21 | 10-bit/8-bit x 6-ch | 3 x 3 x 0.76 |
| R7F102G8E3CLA#HC0 | 64 | 4 | -40 to 105°C | 2 | 21 | 10-bit/8-bit x 6-ch | 3 x 3 x 0.76 |
| R7F102G8E2DLA#AC0 | 64 | 4 | -40 to 85°C | 2 | 21 | 10-bit/8-bit x 6-ch | 3 x 3 x 0.76 |
| R7F102G8E2DLA#BC0 | 64 | 4 | -40 to 85°C | 2 | 21 | 10-bit/8-bit x 6-ch | 3 x 3 x 0.76 |
| R7F102G8E2DLA#HC0 | 64 | 4 | -40 to 85°C | 2 | 21 | 10-bit/8-bit x 6-ch | 3 x 3 x 0.76 |
| R7F102GAC3CSP#AA0 | 32 | 4 | -40 to 105°C | 2 | 26 | 10-bit/8-bit x 8-ch | 10 x 6 x 1.4 |
| R7F102GAC3CSP#BA0 | 32 | 4 | -40 to 105°C | 2 | 26 | 10-bit/8-bit x 8-ch | 10 x 6 x 1.4 |
| R7F102GAC3CSP#HA0 | 32 | 4 | -40 to 105°C | 2 | 26 | 10-bit/8-bit x 8-ch | 10 x 6 x 1.4 |
| R7F102GAC2DSP#AA0 | 32 | 4 | -40 to 85°C | 2 | 26 | 10-bit/8-bit x 8-ch | 10 x 6 x 1.4 |
| R7F102GAC2DSP#BA0 | 32 | 4 | -40 to 85°C | 2 | 26 | 10-bit/8-bit x 8-ch | 10 x 6 x 1.4 |
| R7F102GAC2DSP#HA0 | 32 | 4 | -40 to 85°C | 2 | 26 | 10-bit/8-bit x 8-ch | 10 x 6 x 1.4 |
| R7F102GAE3CSP#AA0 | 64 | 4 | -40 to 105°C | 2 | 26 | 10-bit/8-bit x 8-ch | 10 x 6 x 1.4 |
| R7F102GAE3CSP#BA0 | 64 | 4 | -40 to 105°C | 2 | 26 | 10-bit/8-bit x 8-ch | 10 x 6 x 1.4 |
| R7F102GAE3CSP#HA0 | 64 | 4 | -40 to 105°C | 2 | 26 | 10-bit/8-bit x 8-ch | 10 x 6 x 1.4 |
| R7F102GAE2DSP#AA0 | 64 | 4 | -40 to 85°C | 2 | 26 | 10-bit/8-bit x 8-ch | 10 x 6 x 1.4 |
| R7F102GAE2DSP#BA0 | 64 | 4 | -40 to 85°C | 2 | 26 | 10-bit/8-bit x 8-ch | 10 x 6 x 1.4 |
| R7F102GAE2DSP#HA0 | 64 | 4 | -40 to 85°C | 2 | 26 | 10-bit/8-bit x 8-ch | 10 x 6 x 1.4 |
| R7F102GBC3CNP#AA0 | 32 | 4 | -40 to 105°C | 2 | 28 | 10-bit/8-bit x 8-ch | 5 x 5 x 0.8 |
| R7F102GBC3CNP#BA0 | 32 | 4 | -40 to 105°C | 2 | 28 | 10-bit/8-bit x 8-ch | 5 x 5 x 0.8 |
| R7F102GBC3CNP#HA0 | 32 | 4 | -40 to 105°C | 2 | 28 | 10-bit/8-bit x 8-ch | 5 x 5 x 0.8 |
| R7F102GBC2DNP#AA0 | 32 | 4 | -40 to 85°C | 2 | 28 | 10-bit/8-bit x 8-ch | 5 x 5 x 0.8 |
| R7F102GBC2DNP#BA0 | 32 | 4 | -40 to 85°C | 2 | 28 | 10-bit/8-bit x 8-ch | 5 x 5 x 0.8 |
| R7F102GBC2DNP#HA0 | 32 | 4 | -40 to 85°C | 2 | 28 | 10-bit/8-bit x 8-ch | 5 x 5 x 0.8 |
| R7F102GBE3CNP#AA0 | 64 | 4 | -40 to 105°C | 2 | 28 | 10-bit/8-bit x 8-ch | 5 x 5 x 0.8 |
| R7F102GBE3CNP#BA0 | 64 | 4 | -40 to 105°C | 2 | 28 | 10-bit/8-bit x 8-ch | 5 x 5 x 0.8 |
| R7F102GBE3CNP#HA0 | 64 | 4 | -40 to 105°C | 2 | 28 | 10-bit/8-bit x 8-ch | 5 x 5 x 0.8 |
| R7F102GBE2DNP#AA0 | 64 | 4 | -40 to 85°C | 2 | 28 | 10-bit/8-bit x 8-ch | 5 x 5 x 0.8 |
| R7F102GBE2DNP#BA0 | 64 | 4 | -40 to 85°C | 2 | 28 | 10-bit/8-bit x 8-ch | 5 x 5 x 0.8 |
| R7F102GBE2DNP#HA0 | 64 | 4 | -40 to 85°C | 2 | 28 | 10-bit/8-bit x 8-ch | 5 x 5 x 0.8 |
| R7F102GBC3CFP#AA0 | 32 | 4 | -40 to 105°C | 2 | 28 | 10-bit/8-bit x 8-ch | 7 x 7 x 1.7 |
| R7F102GBC3CFP#BA0 | 32 | 4 | -40 to 105°C | 2 | 28 | 10-bit/8-bit x 8-ch | 7 x 7 x 1.7 |
| R7F102GBC3CFP#HA0 | 32 | 4 | -40 to 105°C | 2 | 28 | 10-bit/8-bit x 8-ch | 7 x 7 x 1.7 |
| R7F102GBC2DFP#AA0 | 32 | 4 | -40 to 85°C | 2 | 28 | 10-bit/8-bit x 8-ch | 7 x 7 x 1.7 |
| R7F102GBC2DFP#BA0 | 32 | 4 | -40 to 85°C | 2 | 28 | 10-bit/8-bit x 8-ch | 7 x 7 x 1.7 |
| R7F102GBC2DFP#HA0 | 32 | 4 | -40 to 85°C | 2 | 28 | 10-bit/8-bit x 8-ch | 7 x 7 x 1.7 |
| R7F102GBE3CFP#AA0 | 64 | 4 | -40 to 105°C | 2 | 28 | 10-bit/8-bit x 8-ch | 7 x 7 x 1.7 |
| R7F102GBE3CFP#BA0 | 64 | 4 | -40 to 105°C | 2 | 28 | 10-bit/8-bit x 8-ch | 7 x 7 x 1.7 |
| R7F102GBE3CFP#HA0 | 64 | 4 | -40 to 105°C | 2 | 28 | 10-bit/8-bit x 8-ch | 7 x 7 x 1.7 |
| R7F102GBE2DFP#AA0 | 64 | 4 | -40 to 85°C | 2 | 28 | 10-bit/8-bit x 8-ch | 7 x 7 x 1.7 |
| R7F102GBE2DFP#BA0 | 64 | 4 | -40 to 85°C | 2 | 28 | 10-bit/8-bit x 8-ch | 7 x 7 x 1.7 |
| R7F102GBE2DFP#HA0 | 64 | 4 | -40 to 85°C | 2 | 28 | 10-bit/8-bit x 8-ch | 7 x 7 x 1.7 |
| R7F102GCC3CLA#BC0 | 32 | 4 | -40 to 105°C | 2 | 32 | 10-bit/8-bit x 8-ch | 4 x 4 x 0.76 |
| R7F102GCC3CLA#AC0 | 32 | 4 | -40 to 105°C | 2 | 32 | 10-bit/8-bit x 8-ch | 4 x 4 x 0.76 |
| R7F102GCC3CLA#HC0 | 32 | 4 | -40 to 105°C | 2 | 32 | 10-bit/8-bit x 8-ch | 4 x 4 x 0.76 |
| R7F102GCC2DLA#BC0 | 32 | 4 | -40 to 85°C | 2 | 32 | 10-bit/8-bit x 8-ch | 4 x 4 x 0.76 |
| R7F102GCC2DLA#AC0 | 32 | 4 | -40 to 85°C | 2 | 32 | 10-bit/8-bit x 8-ch | 4 x 4 x 0.76 |
| R7F102GCC2DLA#HC0 | 32 | 4 | -40 to 85°C | 2 | 32 | 10-bit/8-bit x 8-ch | 4 x 4 x 0.76 |
| R7F102GCE3CLA#BC0 | 64 | 4 | -40 to 105°C | 2 | 32 | 10-bit/8-bit x 8-ch | 4 x 4 x 0.76 |
| R7F102GCE3CLA#AC0 | 64 | 4 | -40 to 105°C | 2 | 32 | 10-bit/8-bit x 8-ch | 4 x 4 x 0.76 |
| R7F102GCE3CLA#HC0 | 64 | 4 | -40 to 105°C | 2 | 32 | 10-bit/8-bit x 8-ch | 4 x 4 x 0.76 |
| R7F102GCE2DLA#BC0 | 64 | 4 | -40 to 85°C | 2 | 32 | 10-bit/8-bit x 8-ch | 4 x 4 x 0.76 |
| R7F102GCE2DLA#AC0 | 64 | 4 | -40 to 85°C | 2 | 32 | 10-bit/8-bit x 8-ch | 4 x 4 x 0.76 |
| R7F102GCE2DLA#HC0 | 64 | 4 | -40 to 85°C | 2 | 32 | 10-bit/8-bit x 8-ch | 4 x 4 x 0.76 |
| R7F102GEC3CNP#AA0 | 32 | 4 | -40 to 105°C | 2 | 36 | 10-bit/8-bit x 9-ch | 6 x 6 x 0.8 |
| R7F102GEC3CNP#BA0 | 32 | 4 | -40 to 105°C | 2 | 36 | 10-bit/8-bit x 9-ch | 6 x 6 x 0.8 |
| R7F102GEC3CNP#HA0 | 32 | 4 | -40 to 105°C | 2 | 36 | 10-bit/8-bit x 9-ch | 6 x 6 x 0.8 |
| R7F102GEC2DNP#AA0 | 32 | 4 | -40 to 85°C | 2 | 36 | 10-bit/8-bit x 9-ch | 6 x 6 x 0.8 |
| R7F102GEC2DNP#BA0 | 32 | 4 | -40 to 85°C | 2 | 36 | 10-bit/8-bit x 9-ch | 6 x 6 x 0.8 |
| R7F102GEC2DNP#HA0 | 32 | 4 | -40 to 85°C | 2 | 36 | 10-bit/8-bit x 9-ch | 6 x 6 x 0.8 |
| R7F102GEE3CNP#AA0 | 64 | 4 | -40 to 105°C | 2 | 36 | 10-bit/8-bit x 9-ch | 6 x 6 x 0.8 |
| R7F102GEE3CNP#BA0 | 64 | 4 | -40 to 105°C | 2 | 36 | 10-bit/8-bit x 9-ch | 6 x 6 x 0.8 |
| R7F102GEE3CNP#HA0 | 64 | 4 | -40 to 105°C | 2 | 36 | 10-bit/8-bit x 9-ch | 6 x 6 x 0.8 |
| R7F102GEE2DNP#AA0 | 64 | 4 | -40 to 85°C | 2 | 36 | 10-bit/8-bit x 9-ch | 6 x 6 x 0.8 |
| R7F102GEE2DNP#BA0 | 64 | 4 | -40 to 85°C | 2 | 36 | 10-bit/8-bit x 9-ch | 6 x 6 x 0.8 |
| R7F102GEE2DNP#HA0 | 64 | 4 | -40 to 85°C | 2 | 36 | 10-bit/8-bit x 9-ch | 6 x 6 x 0.8 |
| R7F102GFC3CFP#AA0 | 32 | 4 | -40 to 105°C | 2 | 40 | 10-bit/8-bit x 10-ch | 10 x 10 x 1.6 |
| R7F102GFC3CFP#BA0 | 32 | 4 | -40 to 105°C | 2 | 40 | 10-bit/8-bit x 10-ch | 10 x 10 x 1.6 |
| R7F102GFC3CFP#HA0 | 32 | 4 | -40 to 105°C | 2 | 40 | 10-bit/8-bit x 10-ch | 10 x 10 x 1.6 |
| R7F102GFC2DFP#AA0 | 32 | 4 | -40 to 85°C | 2 | 40 | 10-bit/8-bit x 10-ch | 10 x 10 x 1.6 |
| R7F102GFC2DFP#BA0 | 32 | 4 | -40 to 85°C | 2 | 40 | 10-bit/8-bit x 10-ch | 10 x 10 x 1.6 |
| R7F102GFC2DFP#HA0 | 32 | 4 | -40 to 85°C | 2 | 40 | 10-bit/8-bit x 10-ch | 10 x 10 x 1.6 |
| R7F102GFE3CFP#AA0 | 64 | 4 | -40 to 105°C | 2 | 40 | 10-bit/8-bit x 10-ch | 10 x 10 x 1.6 |
| R7F102GFE3CFP#BA0 | 64 | 4 | -40 to 105°C | 2 | 40 | 10-bit/8-bit x 10-ch | 10 x 10 x 1.6 |
| R7F102GFE3CFP#HA0 | 64 | 4 | -40 to 105°C | 2 | 40 | 10-bit/8-bit x 10-ch | 10 x 10 x 1.6 |
| R7F102GFE2DFP#AA0 | 64 | 4 | -40 to 85°C | 2 | 40 | 10-bit/8-bit x 10-ch | 10 x 10 x 1.6 |
| R7F102GFE2DFP#BA0 | 64 | 4 | -40 to 85°C | 2 | 40 | 10-bit/8-bit x 10-ch | 10 x 10 x 1.6 |
| R7F102GFE2DFP#HA0 | 64 | 4 | -40 to 85°C | 2 | 40 | 10-bit/8-bit x 10-ch | 10 x 10 x 1.6 |
| R7F102GGC3CFB#AA0 | 32 | 4 | -40 to 105°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 1.7 |
| R7F102GGC3CFB#BA0 | 32 | 4 | -40 to 105°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 1.7 |
| R7F102GGC3CFB#HA0 | 32 | 4 | -40 to 105°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 1.7 |
| R7F102GGC2DFB#AA0 | 32 | 4 | -40 to 85°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 1.7 |
| R7F102GGC2DFB#BA0 | 32 | 4 | -40 to 85°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 1.7 |
| R7F102GGC2DFB#HA0 | 32 | 4 | -40 to 85°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 1.7 |
| R7F102GGE3CFB#AA0 | 64 | 4 | -40 to 105°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 1.7 |
| R7F102GGE3CFB#BA0 | 64 | 4 | -40 to 105°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 1.7 |
| R7F102GGE3CFB#HA0 | 64 | 4 | -40 to 105°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 1.7 |
| R7F102GGE2DFB#AA0 | 64 | 4 | -40 to 85°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 1.7 |
| R7F102GGE2DFB#BA0 | 64 | 4 | -40 to 85°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 1.7 |
| R7F102GGE2DFB#HA0 | 64 | 4 | -40 to 85°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 1.7 |
| R7F102GGC3CNP#AA0 | 32 | 4 | -40 to 105°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 0.8 |
| R7F102GGC3CNP#BA0 | 32 | 4 | -40 to 105°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 0.8 |
| R7F102GGC3CNP#HA0 | 32 | 4 | -40 to 105°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 0.8 |
| R7F102GGC2DNP#AA0 | 32 | 4 | -40 to 85°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 0.8 |
| R7F102GGC2DNP#BA0 | 32 | 4 | -40 to 85°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 0.8 |
| R7F102GGC2DNP#HA0 | 32 | 4 | -40 to 85°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 0.8 |
| R7F102GGE3CNP#AA0 | 64 | 4 | -40 to 105°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 0.8 |
| R7F102GGE3CNP#BA0 | 64 | 4 | -40 to 105°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 0.8 |
| R7F102GGE3CNP#HA0 | 64 | 4 | -40 to 105°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 0.8 |
| R7F102GGE2DNP#AA0 | 64 | 4 | -40 to 85°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 0.8 |
| R7F102GGE2DNP#BA0 | 64 | 4 | -40 to 85°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 0.8 |
| R7F102GGE2DNP#HA0 | 64 | 4 | -40 to 85°C | 2 | 44 | 10-bit/8-bit x 10-ch | 7 x 7 x 0.8 |
