- 產品詳情
Bliley高性能OXCO產品是頻率控制行業85年的成果?，F(xiàn)代布局拓?fù)涫笲liley能夠?yàn)樗袘?yīng)用程序設計和生成強大的設計。
特性:
表面貼裝設計
具有非常高的溫度穩定性
快速熱身時間
低年齡比率
低相位噪聲
9.7x7.7mm包裝
其他型號：
| Family | Type | Freq Range | Stability | Temp Range | PHN, dBc/Hz | Supply | Package |
| BOV-E | OCXO | 10 to 100MHz | ±20ppb, ±50ppb, ±100ppb | -20°C to +70°C, -40°C to +85°C | -120 @ 10Hz -145 @ 100Hz -150 @ 1kHz -155 @ 10kHz -160 @ 100kHz | 3.3v 5.0v 12.0v | 25mm x 25mm |
| BOV-G | OCXO | 2 to 100MHz | ±20ppb, ±50ppb, ±100ppb | -20°C to +70°C, -40°C to +85°C | -120 @ 10Hz -140 @ 100Hz -145 @ 1kHz -150 @ 10kHz -155 @ 100kHz | 3.3v 5.0v | 25mm x 22mm |
| BOV-L | OCXO | 10 to 100MHz | ±20ppb, ±50ppb, ±100ppb | -20°C to +70°C, -40°C to +85°C | -120 @ 10Hz -140 @ 100Hz -145 @ 1kHz -150 @ 10kHz -155 @ 100kHz | 3.3v 5.0v | 14-pin DIP |
| BOV-H | OCXO | 10 to 40MHz | ±20ppb, ±50ppb, ±100ppb | -20°C to +70°C, -40°C to +85°C | (20MHz @ 25C) -70 @ 1Hz -100 @ 10Hz -123 @ 100Hz -143 @ 1kHz -147 @ 10kHz -151 @ 100kHz | 3.3v 5.0v | 9mm x 7mm |
| BOV-J | OCXO | 5 to 100MHz | ±20ppb, ±50ppb | -20°C to +70°C, -40°C to +85°C | -90 @ 1Hz -120 @ 10Hz -140 @ 100Hz -145 @ 1kHz -150 @ 10kHz -155 @ 100kHz | 3.3v 5.0v | 20mm x 20mm |
| BOV-B | OCXO | 10 to 100MHz | ±20ppb, ±50ppb, ±100ppb | -20°C to +70°C, -40°C to +85°C | -120 @ 10Hz -140 @ 100Hz -145 @ 1kHz -150 @ 10kHz -155 @ 100kHz | 5.0v 12.0v | 36mm x 27mm |
| BOV-P | OCXO | 10 to 100MHz | ±20ppb, ±50ppb, | -20°C to +70°C, -40°C to +85°C | -80 @ 1Hz -110 @ 10Hz -140 @ 100Hz -145 @ 1kHz -150 @ 10kHz -155 @ 100kHz | 3.3v 5.0v | 9mm x 14mm |
