TI德州儀器可編程和可變?cè)鲆娣糯笃?(PGA/VGA)

發布時間：2021-08-31 17:19:51 瀏覽：985

TI德州儀器提供各種各樣可變和可編程增益放大器，可以提升電源電路的動態范圍，并可以實時監控調整數據信號振幅。TI德州儀器的產品系列提供行業內領先的零漂移、高精度解決方案，具備從直流到4.5GHz的寬頻率范圍和高達1000V/V的寬增益范圍。

深圳市立維創展科技有限公司，專注于TI 德州老品牌可推出的新品，并備有備品系列儲備，可當天上線。

詳情了解TI德州儀器請點擊：/brand/57.html

或聯系我們的銷售工程師： 0755-83050846 QQ ： 3312069749


Part number	PGA/VGA	Number of channels (#)	BW @ Acl (MHz)	Vs (Max) (V)	Vs (Min) (V)	Acl, min spec gain (V/V)	Gain (Max) (dB)	Slew rate (Typ) (V/us)	Operating temperature range (C)
OPA3S328	---	2	40	5.5	2.2	---	---	25	-40 to 85
LMH2832	VGA	2	1100	5.25	4.75	0.35	30	---	-40 to 85
THS7530-Q1	VGA	1	300	5.5	4.5	3.8	46.5	1250	-40 to 125
LMH6401	VGA	1	4500	5	4	0.5	26	18200	-40 to 85
PGA309-HT	PGA	2	---	5	2.7	---	128	0.5	-55 to 150
PGA281	PGA	1	6	36	10	0.125	42	1	-40 to 125
LMH6523	VGA	4	1400	5.25	4.75	0.5	25.74	---	-40 to 85
VCA5807	VGA	8	200	5.5	3.15	1	54	---	-40 to 85
LMH6882	VGA	2	2400	5.25	4.75	2	26	6000	-40 to 85
LMH6881	VGA	1	2400	5.25	4.75	2	26	6000	-40 to 85
LMH6522	VGA	4	1400	5.25	4.75	0.61	25.74	---	-40 to 85
LMH6521	VGA	2	1400	5.25	4.75	0.53	26	---	-40 to 85
THS770012	PGA	1	900	5	4.75	4	13.7	3400	-40 to 85
LMP7312	---	1	1.2	---	---	0.096	6	1.4	-40 to 125
LMH6517	VGA	2	1200	5.25	4.5	0.33	22	5000	-40 to 85
PGA870	VGA	1	650	5.25	4.75	0.27	20	2900	-40 to 85
PGA280	PGA	4	6	36	10	0.125	42	1	-40 to 125
LMH6518	VGA	1	900	5.25	4.75	0.87	38.8	760	-40 to 85
PGA117	PGA	10	10	5.5	2.2	1	46	3	-40 to 125
PGA116	PGA	10	10	5.5	2.2	1	46	3	-40 to 125
PGA308	PGA	2	---	5.5	2.7	---	---	0.6	-40 to 125
PGA113	PGA	2	10	5.5	2.2	1	42	3	-40 to 125
PGA112	PGA	2	10	5.5	2.2	1	42	3	-40 to 125
VCA8500	VGA	8	55	3.47	3.14	10	51	---	-40 to 85
LMH6514	VGA	1	600	5.25	4	0.25	30	1600	-40 to 85
VCA821	VGA	1	710	12	7	2	40	2500	-40 to 85
VCA824	VGA	1	710	12	8	2	40	2500	-40 to 85
VCA820	VGA	1	150	12	7	10	40	1700	-40 to 85
VCA822	VGA	1	150	12	7	10	40	1700	-40 to 85
LMH6505	VGA	1	150	12	7	1	40	1500	-40 to 85
VCA2615	VGA	2	42	5.25	4.75	2.8	61	100	-40 to 85
VCA2617	VGA	2	50	5.25	4.75	0.32	48	100	-40 to 85
LMH6515	VGA	1	600	5.25	4	0.45	24.2	---	-40 to 85
VCA8617	VGA	8	100	3.15	2.85	1.8	58	300	-40 to 85
VCA810	VGA	1	35	10	10	0.01	40	350	-40 to 85
PGA309	PGA	2	---	5	2.7	---	---	0.5	-40 to 125
LMH6502	VGA	1	130	12	5	1	40	1800	-40 to 85
LMH6503	VGA	1	135	12	5	1	40	1800	-40 to 85
THS7530	VGA	1	300	5.5	4.5	3.8	46.5	1250	-40 to 85
VCA2612	VGA	2	40	5.25	4.75	8	53	300	-40 to 85
THS7001	VGA	1	100	32	9	0.08	20	85	-40 to 85, 0 to 70
THS7002	VGA	2	100	32	9	0.08	20	85	-40 to 85, 0 to 70
PGA103	PGA	1	1.5	36	9	1	40	9	-40 to 85
PGA205	PGA	1	1	36	9	1	18	0.3	-40 to 85
PGA204	PGA	1	1	36	9	1	60	0.3	-40 to 85
PGA203	PGA	1	1	36	12	1	18	15	-25 to 85
PGA202	PGA	1	1	36	12	1	60	15	-25 to 85
LM359	---	2	400	22	5	---	100	60	0 to 70
