HOLT IC?航空電子設備 MIL-STD-1553 耦合變壓器
發布時間:2021-03-25 17:02:51 瀏覽:1101
耦合變壓器既是無線電線路中常常用來極間耦合的變壓器。比如,無線電的中間過渡期、輸入變壓器和輸出變壓器都?xì)w屬于這一類。耦合變壓器的功能模塊多種多樣,也可用作構建阻抗匹配等。MIL-STD-1553使用于HOLT IC耦合變壓器。與HOLT IC隔離變壓器相互配合使用時,其比值應是1:1.4。
基本特征
遵循MIL-STD-1553A/B
共模抑制超過45dB
阻抗試驗頻率75kHz~1MHz
不超過20%的下垂
過沖和振鈴正負1V(最大)
脈沖寬度2微秒
相對濕度敏感性(MSL)3
應用領域
MIL-STD-1553接口
智能化彈藥
店鋪管理
傳感器接口
儀器設備和器材
深圳市立維創展科技有限公司,持續提供HOLT IC預定渠道,部分型號備有現貨庫存,歡迎咨詢。
詳情了解霍爾IC請點擊:http : //899job.com/public/brand/55.html
或聯系我們的銷售工程師: 0755- 83642657 QQ: 2295048674
Part | Package Description | Single or Dual Core | Transformer Ratio |
PM-DB2764 | Surface Mount | Stacked Dual Core | Single Ratio, 1:1.41 per channel |
PM-DB27432 | Surface Mount | Dual Core | Dual Ratio, 1:1.4 and 2:1 |
PM-DB2702 | Through hole | Single Core | Dual Ratio, 1:1.4 or 2:1 |
PM-DB2705 | Through hole | Single Core | Single Ratio, 1:1.41 |
PM-DB2705EX | Through hole | Single Core | Single Ratio, 1:1.41 |
PM-DB2707 | Through hole | Single Core | Single Ratio, 1:1.41 |
PM-DB2712 | Surface Mount | Single Core | Dual Ratio, 1:1.4 or 2.1:1 |
PM-DB2717 | Flat Pack (leads not formed) | Single Core | Dual Ratio, 1:1.41 or 2:1 |
PM-DB2722 | Through hole | Single Core | Dual Ratio, 1:1.4 or 2:1 |
PM-DB27403 | Through hole | Dual Core | Dual Ratio, 1:1.4 and 2:1 |
PM-DB27413 | Through hole | Dual Core | Dual Ratio, 1:1.4 and 2:1 |
PM-DB2742 | Through hole | Single Core | Dual Ratio, 1:1.4 or 2:1 |
PM-DB27423 | Through hole | Dual Core | Dual Ratio, 1:1.4 and 2:1 |
PM-DB2742D | Through hole | Dual Core | Dual Ratio, 1:1.4 and 2:1 |
PM-DB2742L | Surface Mount | Single Core | Dual Ratio, 1:1.4 or 2:1 |
PM-DB2742M | Flat Pack (leads not formed) | Single Core | Dual Ratio, 1:1.4 or 2:1 |
PM-DB2742N | Flat Pack (leads not formed) | Single Core | Dual Ratio, 1:1.4 or 2:1 |
PM-DB2742S | Surface Mount | Dual Core | Dual Ratio, 1:1.4 and 2:1 |
PM-DB2742T | Flat Pack (leads not formed) | Dual Core | Dual Ratio, 1:1.4 and 2:1 |
